Netgear DG834PN
MIMO Wireless G 108Mbps ADSL Modem Router
• ADSL Specifications:
- ADSL, Dual RJ-11, pins 2 and 3, ANSI T1.413, G.DMT, G.Lite (ITU Annex A; Annex B is DG834PNB)
• Routing Protocol:
- Static and Dynamic Routing with TCP/IP, VPN passthrough (IPSec, L2TP, PPTP), NAT, UDP, RIP, PPPoE, PPPoA, Classical IP, DNS, DHCP (client & server)
• Application Support:
-Works with most Internet applications including: Quake®, Half-Life®, StarCraft, Unreal Tournament®, ICQ®, AOL® Instant Messenger™, Microsoft Messenger®, NetMeeting®, RealPlayer®, Windows Media Player™, Net2Phone®, Dialpad®
• Physical Interfaces:
- LAN Ports: Four (4) 10/100 Mbps auto-sensing, Auto Uplink™ RJ-45 ports (one Cat 5 UTP cable included), 802.11g access point and Super G
-WAN Port: ADSL RJ-11, T1.413, G.DMT, G.Lite, ITU Annex A; Annex B version is DG834PNB
-Wireless speeds: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps Super G (auto-rate capable) 108 Mbps
-Modulation Type: OFDM with BPSK, QPSK, 16QAM, 64QAM, DBPSK, DQPSK, CCK
- Frequency:
2.412 ~ 2.462 GHz (US)
2.412 ~ 2.472 GHz (Europe ETSI)
2.457 ~ 2.462 GHz (Spain)
2.457 ~ 2.472 GHz (France)
- Antenna: 6 internal
- Standards Capability: 802.11g
- Non-Standard Capability: Super G
• Security Features:
- Firewall: Stateful Packet Inspection, Intrusion logging and Reporting, Denial of Service protection
- VPN Functionality: NAT traversal (VPN pass-through) for IPSec, PPTP and L2TP VPNs
-Mode of Operation: Network Address Translation (NAT), static routing IP Address Assignment: Static IP address assignment, internal DHCP server on LAN, DHCP client on WAN
-Wireless Security: WEP, WPA-PSK, Disable Access Point, Hide SSID
User Support:
- Up to 253 LAN users
• ADSL Specifications:
- ADSL, Dual RJ-11, pins 2 and 3, ANSI T1.413, G.DMT, G.Lite (ITU Annex A; Annex B is DG834PNB)
