Caratteristiche Hardware
Protocols & Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE 802.3u, ANSI T1.413, ITU G.992.1, ITU G.992.2, ITU G.992.3, ITU G.992.5
Interface 1 x RJ11 port, 1 x 10/100 Mbps auto-negotiation (Auto MDI/MDIX) LAN port, 1 x 10/100 Mbps auto-negotiation WAN/LAN Interchangeable port (Auto MDI/MDIX)
Antenna 2 x External Omni-directional Antennas
Button 1 x Power, 1 x Reset/WPS
Power Input: 100 - 240 V, 50/60 MHz; Output: 9 V DC, 1 A
Temperature Operating Temperature: 0 - 40 Degree C; Storage Temperature: -40 - 70 Degree C
Humidity Operating Humidity: 10 - 90 percent RH Non-condensing; Storage Humidity: 5 - 90 percent RH Non-condensing
Dimensions (L*W*H) mm 133 x 87 x 24.76 mm
LED Power/SYS/Internet/DSL/WLAN/LAN/WPS
Transmission Media Cat.5, Cat.5e, Cat.6, Phone Cable
Wireless Features
Wireless Speed 300 Mbps
Frequency 2.4 GHz
Basic Features Wireless Radio: On/Off; SSID Broadcast: On/Off; WDS: On/Off; Channel: Auto, 1-13; Network Mode: 11b only, 11g only, 11n only, 11bg mixed, 11bgn mixed; Channel Bandwidth: Auto, 20 MHz, 40 MHz
Security Wireless Access Control: Wireless MAC filter; Wireless Security: Enable/Disable, 64-/128-bit WEP, WPA-PSK/WPA2-PSK
Operating Mode Wireless ADSL/ADSL2+ Modem Router, WDS
Software
Internet Connection Type Dynamic IP, Static IP, PPPoE, PPPoA, IPoA
DHCP Server Yes
Virtual Server Yes
Security Port/URL/MAC Filter
DDNS Yes
TR-069 Yes
VPN Pass-through PPPTP, L2TP, Ipsec
Bandwidth Control Yes
Static Route Yes
Logs Yes
VLAN 802.1Q VLAN
Others TR-069, IPV6, IPTV, Bandwidth Control
